Application

These cables are designed for residential and commercial infrastructure. They serve as the connecting medium in power and control panels, cabinets & switchgears. They can also used for the purposes such as stationary and static appliances, motors and for other single phase connections.

• Ratnaflex -M : PVC insulated & sheathed multicore cables suitable for all general purpose wirings for max. operating temperature of 70°C.

• Ratnaflex -M HR : HR PVC insulated & sheathed multicore cales suitable for higher operating temperature of 70°C

• Ratnaflex -M FR : Flame Retardant (FR) multicore cable enhances safety and are suitable for max. operating temperature 70°C.

• Ratnaflex -M HRFR : Heat Resistant (HR) & Flame Retardant (FR) multicore cables are suitable for higher operating temperature up to 85°Cwith enhanced safety

• Ratnaflex -M FR-LSH : Flame Retardant Low Smoke Low Halogen (FR-LSH) cables are suitable for wiring in public places like schools, hospitals, theatres, etc.

Technical Data

• Approvals : IS 694 marked, FIA/TAC

• Conductor : Electrolytic grade annealed copper Class 5 as per IS 8130

• Standard Cable Colour: Black, grey & white

• Voltage Rating : Up to and including 1100V

• Packing : Standard packing of 100 mtr. in coil. Longer length available on requestUp to and including 1100V

Properties

• Temperature range: -15°C to +70°C

• Max. short circuit temperature rating: 160°C

• Self-extinguishing and flame retardant according to IS 10810 P – 61

• Free from 240+ hazardous substance
